Flood tile
FREEA page's one key figure, filled with the Signature.
Every shadcn style · one file
v2.0 · Updated Oct 13Live preview
pnpm dlx shadcn@latest add https://notchset.dev/r/flood-tile.jsonInstallation
pnpm dlx shadcn@latest add https://notchset.dev/r/flood-tile.jsonFree, no account or key. One command for every shadcn style. With the @notchset registry added, @notchset/<name> works too.
Works with React 18.3 or 19 on Tailwind CSS v4, in any shadcn project. What's tested
Install by hand
- 1. No extra packages: React is enough.
- 2. Copy the files to these paths (the source, or save them all as a .zip)
- components/ui/notchset/flood-tile.tsx
- lib/notchset/living.ts
- 3. No stylesheet needed.
- 4. Install what it builds on first: shadcn's cn helper (lib/utils.ts, from npx shadcn init), the theme foundation (its tokens and base styles)
Styles didn't apply?
The CLI adds the styles to the CSS file named in components.json (tailwind.css). Check that it points at your global stylesheet, that the project uses Tailwind CSS v4, and that the file is imported in your root layout. Installed by hand: paste styles.css into that file.
Usage
Import it and pass your content. The props that matter most are listed next.
Example
"use client";
import { FloodTile } from "@/components/ui/notchset/flood-tile";
import { StatusPill } from "@/components/ui/notchset/status-pill";
export default function FloodTileDemo() {
return (
<div className="grid w-full max-w-[720px] grid-cols-2 gap-4 max-[600px]:grid-cols-1">
<FloodTile drift label="HRV · vs your usual" value="+6" unit="ms" pill={<StatusPill tone="ok">Above your usual</StatusPill>} figure={{ kind: "arc", value: 61, low: 47, high: 55 }} caption="Your usual 47–55 ms, last 21 nights" />
<FloodTile label="LDL cholesterol · 16 Oct" value="128" unit="mg/dL" pill={<StatusPill tone="warn">Out of range</StatusPill>} figure={{ kind: "ruler", value: 128, low: 0, high: 99 }} caption="Northside Lab range under 99" />
</div>
);
}This example also uses Status pill. This command installs them with it, so the example pastes as it is:
pnpm dlx shadcn@latest add https://notchset.dev/r/flood-tile.json https://notchset.dev/r/status-pill.jsonAnatomy
Built fromLiving
Source
components/ui/notchset/flood-tile.tsx
Loading the code
Props
label–React.ReactNodewhat the figure is: "Sleep score · last night"
value–React.ReactNodeRequired.
unit–React.ReactNodepill–React.ReactNodethe standing, as a StatusPill (drawn white on the tile)
figure–Figurethe line drawing under the figure: the value against its range, as an arc or a ruler
caption–React.ReactNodeone line under the drawing
Show all 8 propsShow fewer
facts–FloodFact[]the reading's context as facts, a plain label over its value ("Your range" over "47–55 ms"), at most three; preferred over a caption sentence
drift–booleanthe page's one living light: the tile's light drifts slowly (one per page, never beside another living part)
For coding agents
Give your coding assistant the Markdown guide instead of screenshots.
Where agents read it
- Guide for this component: https://notchset.dev/md/flood-tile.md
- Every component, for tools without MCP: /llms.txt
- MCP server:
https://notchset.dev/api/mcp(setup)
Changelog
v2.0.0 · 2026-10-13
Released with the Notchset system.
Used in
The same file, at work in a finished app. Open it live and find it on its pages.
